AHF304127 – Woven Fabric Twill 435g/m2 x 1270mm
Designed and manufactured by HE Composites.
Innovation that performs. Sustainability that lasts.
The HE Composites Woven Fabric – 2×2 Twill represents the next evolution in sustainable, high-performance reinforcement materials.
Engineered with advanced technical fibers, this fabric delivers a strong, lightweight, and environmentally responsible alternative to traditional glass and carbon fiber composites. It combines high stiffness, superior vibration damping, and a refined natural finish, ideal for industries seeking performance without compromise.
Key Features & Benefits
- Eco-Friendly Performance: 100 % natural fibers – renewable, non-toxic, sustainable
- High Strength & Stiffness: Excellent mechanical properties for composite applications
- Superior Vibration Damping: Naturally reduces noise and mechanical resonance
- Versatile Resin Compatibility: Works with epoxy, vinyl ester, polyester, and bio-based resins
- ♻Thermal Stability: Low CTE for dimensional stability with carbon fiber structures
- Radio Transparent: RF-clear across 1–40 GHz, even in thick laminates
- Long Fatigue Life: Reliable under cyclic loading and impact conditions
- Production-Ready: Consistent performance and quality in every batch
Technical Specifications
- Fabric Weight: 435 g/m²
- Width: 1270 mm (1.27 m / 39.37 in)
- Weave Type: 2×2 Twill
- Roll Length: 25 meters
- Price: $55 per meter
- Minimum Order: 25 meters (1 roll)
This 435 gsm fabric is the second-lightest cloth in our range, with a fine, smooth weave ideal for surface plies and visible laminate layers.
Processing & Handling
HE Composites fabrics can be processed using all standard composite manufacturing methods:
- Hand layup
- Vacuum bagging
- Resin transfer molding (RTM)
- Resin infusion
- Autoclave & compression molding
The natural fiber structure promotes excellent resin flow, producing void-free laminates with a clean, consistent finish. Compatible with both synthetic and bio-based resin systems.
Applications
Twill Weave Advantage: The 2×2 twill offers flexibility and conformability — ideal for complex mold shapes and curved surfaces.
Typical Uses:
- Aviation: Interior panels, molded parts, fairings
- Marine: Boat hulls, decking, cabin components
- Automotive: Racing seats, trim panels, non-structural exteriors
- Recreational: Kayaks, canoes, paddleboards, yachts
- Industrial & Architectural: Tanks, facades, wall panels, furniture, moldings, parcel shelves, door liners
Storage & Care
Store in a cool, dry environment away from direct sunlight.
Because is naturally hygroscopic, dry before use if exposed to moisture or humidity.
Shipping
All composite materials are securely shipped via DHL for fast, tracked delivery worldwide.
About HE Composites
At HE Composites, we’re redefining what performance materials can be.
Our mission is to deliver sustainable, high-strength composites that rival traditional reinforcements—empowering industries to build a cleaner, stronger future.
Woven Fabric Plain Uni 240g/m2 x 1270mm
Designed and manufactured by HE Composites.
Innovation that performs. Sustainability that lasts.
The HE Composites 2×2 Woven Twill combines advanced technical fibers with process-driven composite engineering to deliver outstanding performance and environmental responsibility.
A true alternative to traditional reinforcements like glass and carbon fiber, this eco-friendly fabric provides exceptional strength-to-weight ratio, natural vibration damping, and a smooth, professional surface finish—ideal for high-performance composite applications.
Key Benefits
- Sustainable & Eco-Friendly: 100% natural fibers with low environmental impact
- High Strength & Stiffness: Excellent mechanical properties for composite performance
- Superior Vibration Damping: Reduces noise and vibration better than glass or carbon fiber
- Versatile Processing: Compatible with epoxy, vinyl ester, polyester, and bio-resins
- Thermoelastic Stability: Low CTE ensures dimensional stability with carbon fiber
- Radio Transparent: Performs across 1–40 GHz RF spectrum—even in thick laminates
- Reliable Performance: Consistent quality across all production batches
- Long Fatigue Life: Ideal for cyclic loading and high-stress environments
Specifications
- Fabric Weight: 435 g/m²
- Width: 1270 mm (1.27 m / 39.37 in)
- Weave Type: 2×2 Twill
- Roll Length: 25 meters
- Price: $55 per meter
- Minimum Order: 25 meters (1 roll)
This is the second-lightest woven cloth in our range—featuring a fine weave and smooth finish perfect for surface plies and visible laminates.
Processing Information
Process HE Composites fiber/polymer fabrics just like glass or carbon fiber reinforcements:
- Suitable for hand layup, vacuum bagging, resin transfer molding (RTM), and resin infusion
- Works with epoxy, vinyl ester, polyester, and bio-based resin systems
- Excellent resin flow and consolidation, producing void-free laminates with outstanding appearance
Applications
Twill Weave Advantage: The 2×2 pattern allows stretching and conforming to complex mold shapes.
Common Uses:
- Aviation: Small molded parts, interior components
- Marine: Boat hulls, decking, and cabin panels
- Automotive: Racing seats, trim panels, non-structural exteriors
- Recreational: Kayaks, canoes, paddleboards, dinghies, yachts
- Industrial & Architectural: Tanks, facades, panels, furniture, moldings, and door liners
Storage & Care
Store in a cool, dry place away from direct sunlight.
As is naturally moisture-absorbing, drying before use may be required if exposed to high humidity.
Shipping
All composite materials are shipped via DHL for fast and reliable delivery.
About HE Composites
At HE Composites, we specialize in next-generation natural fiber technologies.
Our mission is to replace conventional materials with sustainable, high-performance alternatives—proving that green innovation and engineering excellence can coexist.
MXH6000D127 – Double Bias – 457g/m² x 1270 mm
Designed and manufactured by HE Composites.
Innovation that performs. Sustainability that lasts.
The HE Composites Double Bias Fabric (MXH6000D127) combines cutting-edge technical fibers with advanced composite engineering to deliver strength, flexibility, and environmental responsibility.
As a sustainable alternative to traditional reinforcements such as glass or carbon fiber, this double-bias hemp fabric offers exceptional torsional and shear resistance, superior vibration damping, and a naturally refined appearance. Designed for high-performance composite manufacturing, it performs flawlessly across multiple processing techniques including hand layup, vacuum bagging, and resin infusion.
Key Performance Advantages
- Sustainable & Eco-Friendly: Made from 100 % renewable, non-toxic fibers
- High Specific Strength & Stiffness: Outstanding mechanical performance for demanding composite applications
- Superior Vibration Damping: Absorbs vibration better than glass or carbon fiber
- Versatile Processing: Compatible with epoxy, vinyl ester, polyester, and bio-based resin systems
- Thermally Stable: Low CTE ensures dimensional compatibility with carbon fibers
- Radio Transparent: RF-clear across 1 – 40 GHz even in thick laminates
- Long Fatigue Life: Reliable under cyclic loading and torsional stress
- Consistent Quality: Uniform performance across production batches
Specifications
- Fabric Weight: 457 g/m²
- Width: 1270 mm (1.27 m / 39.37 in)
- Weave Type: Double Bias (+45°/–45°)
- Roll Length: 22.4 meters
- Price: $65 per meter
This mid-weight double-bias hemp cloth provides the ideal balance of strength, drape, and flexibility, enabling seamless lay-up on complex surfaces and compound curves.
Processing & Handling
HE Composites fabrics can be processed using all standard composite manufacturing methods:
- Hand layup
- Vacuum bagging
- Resin transfer molding (RTM)
- Resin infusion
- Autoclave or compression molding
The unique fiber architecture allows excellent resin flow and consolidation, resulting in void-free laminates with a superior surface finish. Compatible with both synthetic and bio-based resin systems, hemp reinforcement can be used alone or combined with other fibers such as glass or carbon to achieve tailored mechanical properties.
Applications
Double Bias Weave Advantages:
The +45°/–45° orientation enhances shear strength, torsional stiffness, and conformability—perfect for complex, curved or load-bearing structures.
Aviation
- Wing and tail surfaces – conforms easily to compound curves
- Structural components – improved torsional and shear resistance
- Lightweight construction – ideal for drones and model aircraft
Marine
- Boat hulls and decks – provides durability and impact resistance
- Stringers and bulkheads – adds structural stiffness and bonding strength
- Joining laminates – reinforces hull and deck connections
- Strip-planked structures – forms watertight and rigid bonds
Automotive
- Structural panels and body parts – lightweight with high strength
- Driveshafts & torque tubes – +45°/–45° orientation resists torsional loads
- Composite reinforcement – compatible with multiple resin systems
Recreational & Sports
- Snowboards & skis – enhanced torsional stiffness and responsiveness
- Kayaks, boats & paddleboards – marine-grade strength and flexibility
- Windsurfing & kitesurfing boards – strong, lightweight construction
Industrial & Architectural
- UAV & aerospace components
- Structural reinforcement frames and panels
- Industrial molds and tooling
- Joining laminates in composite assemblies
Storage & Care
Store fiber/polymer fabrics in a cool, dry place away from direct sunlight.
Because this material is naturally hygroscopic, dry the fabric before use if it has been exposed to humidity.
Shipping
All composite materials are securely shipped via DHL for fast, tracked worldwide delivery.
About HE Composites
At HE Composites, we are redefining the future of advanced materials.
Our mission is to replace traditional composite reinforcements with sustainable, high-performance alternatives—proving that engineering excellence and environmental responsibility can work together.
About HE Composites
Our Mission
HE Composites is a Canadian company focused on developing high-performance bio-composite materials for demanding applications. We combine material innovation with in-house production to deliver reliable, high-quality products directly to our customers.
